Kirchhoff-EQ is an ultimate 32-band parametric EQ plugin built for all critical professional applications.
Kirchhoff-EQ是为所有关键专业应用而构建的终极32波段参数EQ插件。

It has refined sound quality, analogue-matched curves, 15 filter types with continuously variable shape and 32 vintage EQ types modelled from realworld devices.
它有完善的音质,模拟匹配曲线,15种滤波器类型与连续可变形状和32老式EQ类型从现实世界的设备建模。

The builtin dynamic processing functions are highly flexible and have ultra-low distorsion.
内置的动态处理功能高度灵活,具有超低失真。

All these push Kirchhoff-EQ to a next-generation standard.
所有这些都将Kirchhoff-EQ推向了下一代标准。

Ultimate Sound QualityRobust Nyquist-matched Transform
终极音质稳健奈奎斯特匹配变换

Through originally developed “Robust Nyquist-matched Transform”, Kirchhoff-EQ has made digital-domain frequency response more approximate to its analogue counterparts without high frequency cramping as in regular IIR(infinite impulse response) equalizers.
通过最初开发的“稳健nyquist匹配变换”,Kirchhoff-EQ使数字域频率响应更接近其模拟对应物,而不会像常规IIR(无限脉冲响应)均衡器那样产生高频痉挛。

This technique is applied on all filter types in Kirchhoff-EQ.
该技术适用于Kirchhoff-EQ中的所有滤波器类型。

High-Precision Processing
高精度加工

64-bits is mandatory and it’s not negotiable.
64位是强制性的,没有商量的余地。

The internal processing of Kirchhoff-EQ is always in 64-bits (or 117-bits), regardless host DAW’s current working precision.
无论主机DAW当前的工作精度如何,Kirchhoff-EQ的内部处理始终是64位(或117位)。

Psychoacoustic Adaptive Filter Topologies
心理声学自适应滤波器拓扑

All linear filter structures should have same sound on paper.
所有线性滤波器结构在纸上应该有相同的声音。

However in real-world application, round-off errors make every filter structure sound differently: some better in low frequency, some better in high frequency.
然而,在实际应用中,舍入误差使每个滤波器结构听起来不同:有些在低频时更好,有些在高频时更好。

A technology called “Psychoacoustic Adaptive Filter Topologies” has been deployed in Kirchhoff-EQ.
一种被称为“心理声学自适应滤波器拓扑”的技术已经部署在Kirchhoff-EQ中。

Filter structures change themselves to a “best fitting” state along with corresponding band frequency changes, making optimized sound quality in both low and high frequency.
随着相应频带频率的变化,滤波器结构会自行调整到“最佳拟合”状态,从而使低频和高频的音质都达到最佳。

Switchable Ultra-High 117-bits Processing
可切换超高117位处理

Since there’s already 64-bits, why not go further?
既然已经有64位了,为什么不更进一步呢?

Kirchhoff-EQ uses a technique called “Double-Double” to make precision of internal processing reach 117 bits!
Kirchhoff-EQ采用“Double-Double”技术,使内部处理精度达到117位!

This is the first equalizer in the world to reach such precision.
这是世界上第一个达到如此精度的均衡器。

You can switch between 64-bits and 117-bits at any time.
您可以随时在64位和117位之间切换。

It satisfies the most demanding ears.
它能满足最挑剔的耳朵。

* Linear-phase mode always use 64-bits as it is an FIR(finite impulse response) filter, and does not support 117-bits.
*线性相位模式总是使用64位,因为它是FIR(有限脉冲响应)滤波器,不支持117位。

Filter Types15 Unique Filter Types
Filter type15唯一的过滤器类型

low pass, high pass, band pass: continuously variable from 0 dB/oct to 96 dB/oct;
低通、高通、带通:从0 dB/oct到96 dB/oct连续变化;

bell, notch: continuously variable from 12 dB/oct to 96 dB/oct;
钟形缺口:从12 dB/oct到96 dB/oct连续变化;

low shelf, high shelf, tilt shelf: continuously variable from 6 dB/oct to 96 dB/oct;
低搁板,高搁板,倾斜搁板:从6 dB/oct到96 dB/oct连续变化;

f lat tilt and flat top;
F倾斜平直,顶部平直;

sword: has sharper slope than bell, specifically designed to “dig” out resonances.
剑:比钟有更陡的坡度,专门用来“挖”出共振。

brickwall low pass, brickwall high pass, allpass low and allpass high.
砖墙低通,砖墙高通,全通低通,全通高。
